SONO-CELL ^® Medical Balloon Catheter Coating System has mandrels for holding and keeping catheter straight, up to 2 meters long during the thin film coating process. Typical solvents THF, acetone, DMAC, toluene, chloroform; polymers: urethanes, polycarbonates, silicones, styrenes can be used with this system. Call or email for more information and pricing. Several options are available and customization.

Balloon Catheter Coater Model: SNR400 is a precision spray coating system for PCTA angioplasty balloon catheters. It is equipped with reliable and precise ultrasonic atomizer technology for a uniform and smooth coating of the balloons surface.

Standard Features

Ultrasonic spray coating for nano or micron thin film coating.

Sonaer's ultrasonic spray nozzle, with a variety of frequencies and plume shaping attachments to suit the applications.

High efficiency spray, the material usage ratio > 95%., Uniformity: < 5%.

Jigging fixture capable of holding catheters up to 2 meter in length.

Precision Syringe Pump Liquid Dosing/Dispensing.

Full digital ultrasonic generator: Sonaer's multi-DSPs closed loop control technology provides highly stable operation, with Auto Atomization Power Adjustment (AAPA).

Balloon sizes; Length up to 280mm, Diameter; up to 20mm.

Easy loading and unloading for the balloons.

Dual motion system for positioning of the Nozzle and the Balloons during the coating process.

Self-cleaning ultrasonic nozzle prevents clogging.

All system components are compatible with the typical solvents such as; THF, acetone, DMAC, toluene, chloroform, and polymers such as; urethanes, polycarbonates, silicones, styrene.

Exhaust system interface: ready for connecting to exhaust system of workshop or lab.

Integrated control of the nozzle, liquid delivery, and motion system by full color touch panel with user friendly interface.

Full color HMI.

Dimensions (cm): 220 W x 80 D x 180 H, Weight: 350Kg.

Power input: 220VAC 50/60Hz.

Optional Features

Peripheral Stent Coating accessories.

Choice of Syringe pumps.

Choice of Nozzles and Plume Shaping accessories.
